• Tires, LT235/80R17E all-season highway, blackwall
• Spare tire delete. Deletes the spare tire and wheel.
• Wheels, 17" (43.2 cm) painted steel
• Wheel trim, painted center caps
• Bumper, front chrome lower
• Bumper, rear, delete
• Moldings, beltline, Black
• Grille (Chrome surround with Black mesh.)
• Headlamps, LED reflector with incandescent turn signals and LED signature Daytime Running Lamps
• Smoked Amber LED roof marker, (LED)
• Lamps, cargo area, cab mounted integrated with center high mount stop lamp with switch in bank on left side of steering wheel
• Mirrors, outside high-visibility vertical trailering lower convex mirrors, manual-folding/extending (extends 3.31" [84.25mm]), molded in Black
• Glass, solar absorbing, tinted
• Door handles, Black grained

• Audio system, GMC Infotainment System with 7" diagonal color touch-screen, AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth® streaming audio for music and select phones; featuring Android Auto and Apple CarPlay capability for compatible phones
• Audio system feature, 2-speakers (Requires Regular Cab model.)
• Bluetooth® for phone, connectivity to vehicle infotainment system

• Seats, front 40/20/40 split-bench (no storage)
• Seat adjuster, driver 4-way manual
• Seat adjuster, passenger 4-way manual
• Floor covering, rubberized-vinyl (Not available with LPO floor liners.)
• Steering column, Tilt-Wheel, manual with wheel locking security feature
• Steering wheel, urethane
• Driver Information Center, 3.5" diagonal monochromatic display
• Exterior Temperature Display, located in radio display
• Windows, manual (Standard on Regular Cab model. Crew Cab models have power windows standard.)
• Door locks, manual (Requires Regular Cab model.)
• Power outlet, front auxiliary, 12-volt
• USB port, located on instrument panel
• Air conditioning, single-zone
• Mirror, inside rearview, manual tilt
• Assist handles front A-pillar mounted for driver and passenger, rear B-pillar mounted
• Back-up alarm calibration. This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting

• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
• Brake lining wear indicator
• Daytime Running Lamps, LED signature lighting
• Airbags, Dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Tire Pressure Monitoring System with Tire Fill Alert (does not apply to spare tire)
• Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver

FLEET CONVENIENCE PACKAGE

• includes (AQQ) Remote Keyless Entry
• (K34) cruise control and (DBG) outside power-adjustable vertical trailering with heated upper glass mirrors
• (AXG) power windows
• express up/down driver
• (AED) power windows
• express down passenger and (AU3) power door locks.

WORK TRUCK PREFERRED EQUIPMENT GROUP

• includes standard equipment

SEATS, FRONT 40/20/40 SPLIT-BENCH (NO STORAGE)

• (STD)

AUDIO SYSTEM, GMC INFOTAINMENT SYSTEM WITH 7" DIAGONAL COLOR TOUCH-SCREEN, AM/FM STEREO

• with seek-and-scan and digital clock
• includes Bluetooth® streaming audio for music and select phones; featuring Android Auto and Apple CarPlay capability for compatible phones (STD)

GMC 4G LTE

• and available built-in Wi-Fi hotspot offers a fast and reliable Internet connection for up to 7 devices; includes data trial for 1 month or 3GB (whichever comes first)

SNOW PLOW PREP PACKAGE

• includes (KW5) 220-amp alternator
• includes increased front GAWR on Heavy Duty models
• (NZZ) skid plates (transfer case and oil pan)
• pass through dash grommet hole and roof emergency light provisions.

SKID PLATES

• protect the oil pan
• front axle and transfer case

REAR CAMERA KIT.

• Kit includes camera
• fixed position bracket & 19 ft cable with attachment clips. Rear camera radio calibration provided from the factory. See Upfitter Integration Bulletin for installation instructions at www.gmupfitter.com

UPFITTER SWITCH KIT, (5)

• Provides 3-30 amp and 2 - 20 amp configurable circuits to facilitate installation of aftermarket electrical accessories. Kit with all required parts will be shipped loose with the truck for installation by the dealer or upfitter at customer expense. Installation instructions and technical assistance available at www.gmupfitter.com.

DPF, DIESEL PARTICULATE FILTER, MANUAL REGENERATION

• customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown

FUEL TANK, REAR ONLY, 40 GALLON

• mounted between frame side rails and behind rear axle

SPARE TIRE DELETE.

• Deletes the spare tire and wheel. (STD)

• 14,000 lbs (6,350 Kgs) GVWR
• 17' Painted Steel Wheels
• 2-Speed Active Transfer Case
• 4-Way Manual Driver Seat Adjuster
• 4-Way Manual Passenger Seat Adjuster
• 40 Gallon (151L) Rear Only Fuel Tank
• Cardinal Red
• CT/DE/ME/MD/MA/NJ/NY/OR/PA/RI/VT/WA Emissions Requirements
• Front License Plate Kit
• Integrated Trailer Brake Controller
• Jet Black
• LT235/80R17E AT BW Tires
• Manual Regeneration Diesel Particulate Filter DPF
• Power Door Locks
• Power Front Windows with Driver Express Up/down
• Power Front Windows with Passenger Express Down
• Power-Adjustable Black Outside Mirrors
• Remote Keyless Entry
• Rubberized-Vinyl Floor Covering
• SEO: Rear Camera Kit
• Steering Wheel-Mounted Cruise Control
• Suspension Package
• Upfitter Switch Kit (5)
• AM/FM Radio with GMC Infotainment System
• Duramax 6.6L Turbo-Diesel V8 Engine
• Fleet Convenience Package
• OnStar and GMC Connected Services Capable
• Preferred Equipment Group 1SA
• Snow Plow Prep Package
• 12V power outlets 1 12V power outlet
• 2 Speakers
• 2-Speaker Audio System Feature
• 2-Speed Electronic Shift Transfer Case
• 220 Amp Alternator
• 4-Wheel Disc Brakes
• 4G LTE Wi-Fi Hotspot Capable
• 4WD type AutoTrac part and full-time 4WD
• ABS brakes
• ABS Brakes 4-wheel antilock (ABS) brakes
• ABS Brakes Four channel ABS brakes
• Accessory power Retained accessory power
• Air Conditioning
• Air conditioning Yes
• Alternator Type Alternator
• AM/FM radio
• Antenna Fixed audio antenna
• Apple CarPlay/Android Auto
• Audio theft deterrent Audio system theft deterrent
• Auto door locks Auto-locking doors
• Auto headlights Auto on/off headlight control
• Auxiliary camera
• Basic warranty 36 month/36,000 miles
• Battery charge warning
• Battery run down protection
• Battery type Dual lead acid batteries
• Beverage holders Front beverage holders
• Block heater Engine block heater
• Body panels Galvanized steel/aluminum body panels with side impact beams
• Brake assist
• Brake assist system
• Brake pad warning Brake pad wear indicator
• Brake type DuraLife 4-wheel disc brakes
• Bumper rub strip front Black front bumper rub strip
• Bumpers front Chrome front bumper
• Bumpers: chrome
• Cab mounted cargo light
• Cabback insulator
• Chrome Surround Grille w/Black Mesh
• Clearance lights Cab clearance lights
• Climate control Manual climate control
• Clock Digital clock
• Compass
• Compressor Intercooled turbo
• Convex spotter Driver and passenger convex spotter mirrors
• Corrosion perforation warranty 72 month/100,000 miles
• Cruise control Cruise control with steering wheel mounted controls
• Cylinder head material Aluminum cylinder head
• Day/Night rearview mirror
• DEF fluid gauge Diesel exhaust fluid (def) gauge
• Delay off headlights Delay-off headlights
• Delay-off headlights
• Door ajar warning
• Door bins front Driver and passenger door bins
• Door handle material Black door handles
• Door mirror style Black door mirrors
• Door mirror type Manual extendable trailer mirrors
• Drive type Four-wheel drive
• Driver door bin
• Driver foot rest
• Driver information center
• Driver seat direction Driver seat with 4-way directional controls
• Dual front impact airbags
• Dual front side impact airbags
• Dual rear wheels
• Electronic Stability Control
• Electronic stability control StabiliTrak w/Proactive Roll Avoidance electronic stability control system with anti-roll
• Emissions Federal emissions
• Engine Block Heater
• Engine block material Iron engine block
• Engine Configuration Duramax V8
• Engine cooler Engine oil cooler
• Engine Duramax 6.6L V-8 diesel direct injection, intercooled turbo, diesel, engine with 445HP
• Engine Location Front mounted engine
• Engine Mounting direction Longitudinal mounted engine
• Engine retarder Engine retarder system
• Engine Short Duramax 6.6L V-8
• Engine temperature warning
• Engine/electric motor temperature gauge
• Exhaust Brake
• External memory GMC Infotainment System external memory control
• Floor coverage Full floor coverage
• Floor covering Full vinyl floor covering
• Folding door mirrors Manual folding door mirrors
• Front 40/20/40 Split-Bench Seat
• Front anti-roll bar
• Front anti-roll Front anti-roll bar
• Front beverage holders
• Front head restraint control Manual front seat head restraint control
• Front head restraints Height adjustable front seat head restraints
• Front impact airbag driver Driver front impact airbag
• Front impact airbag passenger Passenger front impact airbag
• Front reading lights
• Front seat type Split-bench front seat
• Front seat upholstery Cloth front seat upholstery
• Front seatback upholstery Plastic front seatback upholstery
• Front side impact airbag driver Seat mounted side impact driver airbag
• Front side impact airbag passenger Seat mounted side impact front passenger airbag
• Front wheel independent suspension
• Fuel Type Diesel
• Fully automatic headlights
• Gearshifter material Urethane gear shifter material
• Glove box Locking glove box
• Grille style Black grille with chrome surround
• Handsfree Bluetooth® handsfree wireless device connectivity
• HD front springs Heavy-duty front springs
• Headlight type Reflector headlights
• Headlights LED low and high beam headlights
• Headlights on reminder
• Headliner coverage Full headliner coverage
• Headliner material Cloth headliner material
• Heated door mirrors Heated driver and passenger side door mirrors
• Heavy-Duty 80 Amp Battery
• High mount stop light High mounted center stop light
• Hill start assist Hill Start Assist (HSA)
• Ignition Compression ignition system
• Ignition type Mechanical
• Illuminated entry
• Immobilizer
• Instrumentation display Analog instrumentation display
• Interior courtesy lights Fade interior courtesy lights
• Internet access 4G LTE Wi-Fi Hotspot capable mobile hotspot internet access
• Key in vehicle warning
• Keyfob keyless entry
• Keyfob window controls Keyfob window control
• License plate front bracket Front license plate bracket
• Lock-up transmission
• Locking hub control Auto locking hub control
• Low level warnings Low level warning for coolant, fuel, washer fluid, brake fluid and diesel exhaust fluid (DEF)
• Low tire pressure warning
• Low tire pressure warning Tire specific low air pressure warning
• Maintenance warranty 12 month/unlimited
• Manual driver seat controls Driver seat manual reclining and fore/aft control
• Manual passenger seat controls Passenger seat manual reclining and fore/aft control
• Manual Windows
• Multiple headlights Multiple enclosed headlights
• Number of airbags 6 airbags
• Number of beverage holders 4 beverage holders
• Number of doors 2 doors
• Number of first-row screens 1 total number of 1st row displays
• Occupancy sensor Airbag occupancy sensor
• Occupant sensing airbag
• Oil pressure gauge
• Oil pressure warning
• One-touch down window Driver and passenger one-touch down windows
• One-touch up window Driver one-touch up window
• OnStar & GMC Connected Services Capable
• Outside temperature display
• Overdrive transmission
• Overhead airbag
• Overhead airbags Curtain first-row overhead airbags
• Overhead console
• Overhead console Mini overhead console
• Paint Non-metallic paint
• Passenger door bin
• Passenger seat direction Front passenger seat with 4-way directional controls
• Passenger vanity mirror
• Perimeter approach lighting Remote activated perimeter approach lighting
• Power Front Windows w/Driver Express Up/Down
• Power Front Windows w/Passenger Express Down
• Power steering
• Powertrain type ICE
• Powertrain warranty 60 month/60,000 miles
• Premium audio system: GMC Infotainment System
• Primary display size 7 inch primary display
• Primary display touchscreen Primary monitor touchscreen
• Provisions Snow plow provisions
• Radiator
• Radio AM/FM
• Radio: AM/FM w/GMC Infotainment System
• Rear locking differential Automatic rear locking differential
• Rear Springs Regular grade rear springs
• Rear windshield Fixed rear windshield
• Remote panic alarm
• Restricted driving mode/alerts Teen Driver restricted driving mode/alerts
• Roadside warranty 60 month/60,000 miles
• Running lights LED daytime running lights
• Seatbelt pretensioners Front seatbelt pretensioners
• Seatbelt pretensioners number 2 seatbelt pre-tensioners
• Seating capacity 3
• Seek scan
• Selectable mode transmission Tow/Haul Mode selectable mode transmission
• Service interval warning Service interval indicator
• Shock absorbers Gas-pressurized shock absorbers
• Skid plate 3 underbody skid plates
• Skid Plates
• Smart device integration Apple CarPlay/Android Auto smart device mirroring
• Solar Absorbing Tinted Glass
• Speakers number 2 speakers
• Speakers Standard grade speakers
• Special paint Monotone paint
• Speedometer Redundant digital speedometer
• Split front seats 40-20-40 split-bench front seat
• Springs front Front torsion springs
• Springs rear Rear leaf springs
• Steering Hydraulic power-assist steering system
• Steering type Re-circulating ball steering
• Steering wheel material Urethane steering wheel
• Steering wheel tilt Manual tilting steering wheel
• Suspension Heavy-duty ride suspension
• Suspension ride type front Independent front suspension
• Suspension ride type rear Rigid axle rear suspension
• Suspension type front Short and long arm front suspension
• Suspension type rear Leaf spring rear suspension
• Tachometer
• Tailpipe Stainless steel single exhaust
• Temperature display Exterior temperature display
• Tilt steering wheel
• Tinted windows Light tinted windows
• Tire pressure Tire Fill Alert tire pressure fill assist
• Tow hooks front 2 front tow hooks
• Towing brake controller Trailer brake controller
• Towing trailer sway Trailer sway control
• Traction control
• Traction control All-speed ABS and driveline traction control
• Transfer case Electronic transfer case shift
• Transmission Allison 10-speed automatic
• Transmission electronic control
• Transmission fluid temperature warning Transmission fluid temp warning
• Transmission oil cooler
• Transmission Type Automatic
• Trim rings Wheel trim rings
• Trip computer
• Trip odometer
• Turn signal in door mirrors Turn signal indicator in door mirrors
• Turn signal warning Turn signal on warning
• Two-Speed Transfer Case
• Upfitter switches
• USB ports 1 USB port
• Variable panel light Variable instrument panel light
• Variably intermittent wipers
• Ventilated brakes Front and rear ventilated disc brakes
• Vinyl Seat Trim
• Visor passenger mirror Passenger visor mirror
• Voice activated audio GMC Infotainment System voice activated audio controls
• Voltmeter
• Wheel covers Wheel hub covers
• Wheels 17 x 6.5-inch front and dual rear painted steel wheels
• Window Trim Black side window trim
• Winter Grille Cover
• Wipers Variable intermittent front windshield wipers
• Wireless streaming Bluetooth® wireless audio streaming

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 730
• Cold Cranking Amps @ 0° F (Primary): 720
• Cold Cranking Amps @ 0° F (2nd): 730
• Maximum Alternator Capacity (amps): 220
• Maximum Alternator Capacity (amps): 170
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 6000
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Front (lbs): 4400
• Gross Axle Wt Rating - Rear (lbs): 10400
• Curb Weight - Front (lbs): 3858
• Curb Weight - Rear (lbs): 2562
• Gross Vehicle Weight Rating Cap (lbs): 14000
• Gross Combined Wt Rating (lbs): 40000
• Gross Combined Wt Rating (lbs): 24000
• Suspension
• Suspension Type - Front: - TBD -
• Suspension Type - Rear: - TBD -
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: - TBD -
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.42
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Stabilizer Bar Diameter - Front (in): 1.38
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.79
• Tires
• Front Tire Order Code: QZT
• Front Tire Order Code: QQO
• Rear Tire Order Code: QZT
• Rear Tire Order Code: QQO
• Front Tire Size: LT235/80R17E
• Rear Tire Size: LT235/80R17E
• Front Tire Capacity (lbs): 3085
• Front Tire Capacity (lbs): 2680
• Front Tire Capacity (lbs): 2515
• Rear Tire Capacity (lbs): 2833
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 6.5
• Rear Wheel Size (in): 17 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 57.5
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 40
• Fuel Tank Capacity, Approx (gal): 63.5
• Aux Fuel Tank Capacity, Approx (gal): 40
• Fuel Tank Location: Rear
• Fuel Tank Location: Front
• Aux Fuel Tank Location: Rear
• Exterior Dimensions
• Wheelbase (in): 146.3
• Length, Overall (in): 239.84
• Width, Max w/o mirrors (in): 80.84
• Height, Overall (in): 80.1
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): 126.65
• Cab to Axle (in): 60
• Cab to End of Frame (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): 89.15
• Ground Clearance, Front (in): 8.15
• Ground Clearance, Rear (in): 8.15
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 43.11
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61
• Summary
• Vehicle Name: GMC Sierra 3500HD CC
• Body Style: Regular Cab Chassis Cab
• Body Code: ZW9
